Go Green >Energy saving date comparison





NORMAL COOLING TOWER
NO. AREA WATER FLOW (CBM) QUANTITY（SET） SERVE HOURS/ DAY RUNNING DAYS POWER （KW） PRICE / CELL PRICE/ SET SAVED RUNNING HOURS ACTUAL RUNNING HOURS/ DAY RUNNING HOURS/ YEAR TOTAL POWER CONSUMPTION/ YEAR (KW) ELECTRICITY PRICE（RMB） ELECTRICITY CHARGE/YEAR (RMB） ELECTRICITY CHARGE FOR 5 YEARS (RMB)
1 　 150 1 24 300 4.00 　 　 0 24 7200 28800 0.8 23040 115200
2 　 250 1 24 300 7.50 　 　 0 24 7200 54000 0.8 43200 216000
3 　 300 1 24 300 11.00 　 　 0 24 7200 79200 0.8 63360 316800
4 TOTAL 　 3 　 　 　 　 　 　 　 　 162000 　 129600 648000
JUMSEN ENERGY-SAVING SERIES COOLING TOWER
NO. AREA WATER FLOW (CBM) QUANTITY（SET） SERVE HOURS/ DAY RUNNING DAYS POWER （KW） PRICE / CELL PRICE/ SET SAVED RUNNING HOURS ACTUAL RUNNING HOURS/ DAY RUNNING HOURS/ YEAR TOTAL POWER CONSUMPTION/ YEAR (KW) ELECTRICITY PRICE（RMB） ELECTRICITY CHARGE/YEAR (RMB） ELECTRICITY CHARGE FOR 5 YEARS (RMB)
1 　 150 1 24 300 4.00 　 　 11 13 3900 15600 0.8 12480 62400
2 　 250 1 24 300 7.50 　 　 11 13 3900 29250 0.8 23400 117000
3 　 300 1 24 300 11.00 　 　 11 13 3900 42900 0.8 34320 171600
4 TOTAL 　 3 　 　 　 　 　 　 　 　 87750 　 70200 351000
　 　 　 　 　 　 　 　 　 　 　 　 -74250 　 -59400 -297000
                            -45.83% -45.83%
PRINCIBLE OF JUMSEN ENERGY-SAVING SYSTEM：
(The analysis below is according to the maximum air's wet bulb temperature in every season.) Water temperature changes with air temperature in different season, and relate to ambient temperature, wet bulb temperature and humidity. The bigger humidity difference is, the better performance of heat exchange is made. Our energy-saving system will swith off the fun motor, in condition that the natural air cooling can meet cooling requirement (as following time). Approx 14 hours in spring (from 5:00pm-7:00am); 3 hours in summer (2:00am-5:00am); 12 hours in Autumn (6:00pm-6:00am); 15 hours in winner (5:00pm-8:00am).
BENEFIT OF JUMSEN ENERGY-SAVING SYSTEM:
1) 45.83% reduction of total power consumption has been made, that makes motor life longer.
2) 59400RMB of electricity charge has been saved, cause of Jumsen energy-saving system. Jumsen energy-saving controller has 2 years warranty, and we promise free replacement in warranty period.
3) 297,000RMB was saved in 5 years, other than normal cooling tower.
4) Jumsen energy-saving system expand 15 years' life of cooling tower, as per 7200 hours running time each year.
5) Not only electricity charge is saved, the labor cost is also saved.
